INMAR 530-SR-HD (17' 8") Search & Rescue Series Inflatable Boat + DF40ATL Motor

INMAR 17' 8" DF40ATL package deal boat outboard, military, patrol, search and rescue, Inflatable

Alternative Views:

M.S.R.P. $11,045.95

Product Code: 530-SR-HD-DF40ATL

Qty:

Description

BOAT

Specifications:

Length 17' 8"
Beam 7' 2"
Weight w/ floor: 340 lbs.
Weight capacity: 12 persons / 2,985 lbs.
Max HP / Weigh: 60 HP / 250 lbs / Long shaft (20")
Recommended HP: 40 HP
Tube diameter 22" (Separate air chambers 5 + 1)
Fabric: Mehler
Seams: RF welded / temperature resistance -30 °C / +70 °C
Factory warranty: 3 years recreational / 2 year commercial
Performance Tubes - Speed & stability (Optional)
Chambers 5 - Inflation and over inflation (One per chamber)
Self-bailers (1) *optional High flow scupper can be added

Standard Features:

Non-skid aluminum floor with anodized aluminum stringers
Fiberglass transom
Transom splash guards
Aluminum engine mounting plate
Reinforcement on tube transom attachments
Standard pop-up self-bailers (internal release)
All around rub strake, flat profile, black
Rubbing strakes for beaching on keel and tubes
10 carry handles, soft handle neoprene covered nylon
Bow handle (Stainless)
Exterior/Interior lifelines (Peripheral)
11 Interior tie down D-rings (Stainless steel)
2 large tow rings on bow (Stainless steel)
4 large tow rings on rear tubes(Stainless steel)
Foot pump with hose & gauge (1) included
Repair kit (1) included
Storage bags, floor (1) hull (1)
Paddle set (Alum. shaft, plastic blade)

OUTBOARD

Specifications:

Horsepower: 40 HP
Drive Type: Remote Steering
Shaft Length: 20" (Long)
Starting: Electric Start
Gears: F - N - R
Weight: 229 lbs
Propeller Included: No
3 Year Warranty
Power Trim and Tilt

Technical Specs

Model Name: DF40
Configuration: A
Horsepower: 40
Shaft Length (Inches): L (20)
Weight (Lbs): 229
Cylinders: In-line 3
Valves Per Cylinder: DOHC 4 Valves Per Cyl.
Valve Train Drive: Self adjusting oil bathed timing chain
Displacement: 57.4 cu. in. (941 cc)
Bore and Stroke (Inches/mm): 2.85 x 2.99 in. (72.5 x 76 mm)
Operating Range (RPM): 5000-6000
Induction System: Sequential EFI with Lean Burn Control
Starting System: Suzuki Easy Start System
Lubrication: Wet sump
Oil Tank Capacity: 2.9 qt. (2.7 lit.)
Ignition: Direct Ignition
Alternator: 12V 19A
Trim Type: Power Trim and Tilt
Gear Ratio: 2.27:1
CARB Emissions Rating: 3-Star Ultra-Low
Standard Propeller (Blades x Dia. x Pitches (Ins.)): Optional - See Dealer
Range of Avail. Optional Propeller Pitches: 9 - 17
Steering: Remote
